    Stone Oblique Chipway Mining Drilling Bit Tapered Drill 7 Degree

    Ask Lasest Price
    Brand Name : MIROC
    Model Number : 4148300109-4148300122
    Delivery Time : 25 days
    Payment Terms : T/T or L/C
    Supply Ability : 20000 pieces per month
    Price : negotiation
    • Product Details
    • Company Profile

    Stone Oblique Chipway Mining Drilling Bit Tapered Drill 7 Degree

    Stone Oblique Chipway Mining Drilling Bit Tapered Drill 7 Degree


    Description


    Tapered equipment affords drillers the ability to change drilling bits whilst still using the same drilling rod. Drillers choose tapered chisel bits if the goal is to minimize hole deviation in small hole range drilling. Different taper sizes have different characteristics when it comes to the “knock-off” index – the smaller angle will prevent the bit from spinning.

    • Suitable for small hole range
    • Widely used in Dimensional Stone Quarrying Industry
    • Widely used in Underground Mining Industry


    Color: Green,Blue or Based on Customer requirements


    Material: Tungsten carbide and high strength alloy steel


    Processing: CNC milling and proprietary heat treatment process


    Type: 7° Tapered Oblique Chipways Chisel Bit



    Applications


    • Dimensional Stone Industry
    • Underground Mining
    • Tunneling



    Competitive Advantage


    • High grade tungsten carbide inserts
    • Bit bodies manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment



    specification


    Part Number

    Product Code and

    Brief Description

    Bit Diameter

    (mm)

    Bit Diameter

    (inch)

    Tip Size

    (W x H, mm)

    Weight

    (kg)

    4148300109

    OC20-4D-19,

    7° Taper Oblique Chipways Chisel Bit

    204/512 x 60.1
    4148300110

    OC22-4D-19,

    7° Taper Oblique Chipways Chisel Bit

    226/712 x 60.12
    4148300111

    OC24-4D-19,

    7° Taper Oblique Chipways Chisel Bit

    24112 x 60.14
    4148300112

    OC26-4D-19,

    7° Taper Oblique Chipways Chisel Bit

    26112 x 60.16
    4148300113

    OC28-7D-19,

    7° Taper Oblique Chipways Chisel Bit

    281 1/913 x 80.19
    4148300114

    OC30-7D-22,

    7° Taper Oblique Chipways Chisel Bit

    301 1/613.5 x 80.22
    4148300115

    OC32-7D-22,

    7° Taper Oblique Chipways Chisel Bit

    321 1/413.5 x 80.24
    4148300116

    OC33-7D-22,

    7° Taper Oblique Chipways Chisel Bit

    331 2/713.5 x 80.25
    4148300117

    OC34-7D-22,

    7° Taper Oblique Chipways Chisel Bit

    341 1/313.5 x 80.27
    4148300118

    OC36-7D-22,

    7° Taper Oblique Chipways Chisel Bit

    361 3/713.5 x 80.29
    4148300119

    OC38-7D-23,

    7° Taper Oblique Chipways Chisel Bit

    381 1/213.5 x 80.34
    4148300120

    OC40-7D-23,

    7° Taper Oblique Chipways Chisel Bit

    401 4/713.5 x 9.20.4
    4148300121

    OC41-7D-23,

    7° Taper Oblique Chipways Chisel Bit

    411 3/513.5 x 9.20.41
    4148300122

    OC42-7D-23,

    7° Taper Oblique Chipways Chisel Bit

    421 2/313.5 x 9.20.43
