    Tungsten Carbide Mining Drill Bits With R28 R32 Threaded Spherical and Ballistic Buttons

    Ask Lasest Price
    Brand Name : MIROC
    Model Number : 4148300437-4148300520
    Certification : ISO9001
    Price : negotiation
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 30000pcs per month
    Delivery Time : 10-22days
    • Product Details
    • Company Profile

    Tungsten Carbide Mining Drill Bits With R28 R32 Threaded Spherical and Ballistic Buttons

    R28 R32 Threaded Tungsten Carbide Rock Drill Button Bit With Spherical/Ballistic Buttons


    Describtion


    Thread button drill bits are made by high quality alloy steel bar and tungsten carbides. Through heat treatment, our drilling tools are tough enough to meet rock drilling demands and have the least loss of energy while drilling the rocks. Besides, we can design customized thread button drill bits according to different drilling application, and custom drill bits are applicable to drill soft rock, loose-medium rock and hard rock.


    R25 Button bits, normal skirt.
    DiameterT.C buttonsFlushing holeAngleWeight
    mminchGauge x mmFront x mmSideFrontGaugeKg
    3811/25x92x71130°0.53
    3811/24x92x82130°0.56
    4115/85x92x81135°0.63
    4115/84x92x82135°0.64
    43111/165x102x82135°0.68
    43111/166x93x81335°0.68
    4513/44x112x92135°0.82
    4513/45x112x82130°0.80
    4513/46x93x81335°0.84
    4817/86x93x91335°0.85
    5125x112x102135°1.05
    5126x113x101335°1.11
    5126x103x91335°1.14

    1) Thread Types: R25 R28 R32 T38 T45 T51...

    2) Alloy steel:45CrNiMo

    3) Suitable carbide tips YK05

    4) Diameter: 30-127mm

    5)Technology:hot-pressing or welding

    6) Suitable: drifting and tunneling, bench drilling


    Specification

    Tungsten Carbide Mining Drill Bits With R28 R32 Threaded Spherical and Ballistic Buttons


    Tungsten Carbide Mining Drill Bits With R28 R32 Threaded Spherical and Ballistic Buttons


    Tungsten Carbide Mining Drill Bits With R28 R32 Threaded Spherical and Ballistic Buttons


    KSQ Related Rock Drilling Tools

    (1) Integral Drill Rod– chisel bit integral rod and plug hole integral drill steel,

    Shank H19 x 108mm and H22 108mm.


    (2) Tapered Rock Drill Tools - chisel bit, cross bit, button bit, drill rod of taper 7, 11, 12 degree


    (3) Threaded Rock Drill Tools - button bit, retrac button bit, drop center button bit, dome bit, reaming bit,extension rod, MF-Rod, Hex rod, coupling sleeve, crossover coupling of thread R25, R28, R32, R38, T38, T45, T51, ST58, ST68.


    (4) Shank Adapters (Striking Bars) - equivalent to Atlas Copco, , Furukawa, Gardner Genver, Ingersoll Rand etc.


    (5) Down-the-hole (DTH) Bits& Hammers - 3'', 4'', 5'', 6'', 8'' hammer and DTH button bit (diameter 80mm - 305mm)


    Other products: Tricone bits, PDC bits, self- drilling hollow anchor bar etc.


    Company Information

    KSQ Technologies (Beijing) Co. Ltd. has significant experience and know-how in the supply of materials, components, finished goods, specially designed/engineered equipment, and services from China. The company caters to medium to large scale clients who are doing projects and capital expansion, as well as to firms who require support with consumable products, maintenance, and repair operations.
